Processor
Built-in processor: Yes
Features
Product colour: White
Power
Power over Ethernet (PoE) power per port: 25.5 W
Power consumption (max): 36 W
Power consumption (typical): 10 W
Output current: 1.22 A
Output voltage: 53 V
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): -20 - 60%
Storage temperature (T-T): 10 - 93 °C
Weight & dimensions
Width: 204.6 mm
Package width: 364 mm
Depth: 206.4 mm
Package weight: 1.42 kg
Height: 45.6 mm
Package height: 261 mm
Package depth: 96 mm
Weight: 480 g
System requirements
Browser supported: Chrome, IE, Safari, Edge, Firefox
Mobile operating systems supported: Android, iOS
Performance
Operating system installed: Embedded LINUX
Backup function: Yes
Video formats supported: H.264+, H.265+, H.265, M-JPEG
Video input channels: 4 channels
Audio formats supported: G.726, G.711 A-law, G.711 μ-law
Input bandwidth: 80 Mbit/s
Number of simultaneously playbacked channels: 4 channels
Video motion detection: Yes
Output bandwidth: 60 Mbit/s
Maximum resolution: 3840 x 2160 pixels
Wireless LAN features
Wi-Fi: No
Ports & interfaces
VGA (D-Sub) output ports: 1
Power over Ethernet (PoE): Yes
HDMI output: Yes
Audio RCA outputs: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
Power over Ethernet (PoE) ports quantity: 4
Audio RCA inputs: 1
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 100, 10
DC-in jack: Yes
Networking standards: IEEE 802.3af, IEEE 802.3at
Hard drive
Number of HDDs supported: 1
Maximum storage capacity: 20 TB
HDD interface: SATA
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
