Processor
Built-in processor: Yes
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Features
Rack mounting: Yes
Product colour: Black
Rack capacity: 1U
Power
Output voltage: 53 V
Power consumption (typical): 36 W
Output current: 1.22 A
Power consumption (max): 25.5 W
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 93%
Weight & dimensions
Package width: 374 mm
Package depth: 119 mm
Width: 260 mm
Package weight: 1.85 kg
Height: 47.6 mm
Weight: 850 g
Package height: 311 mm
Depth: 232.5 mm
System requirements
Browser supported: Chrome; IE; Safari; Edge; Firefox
Mobile operating systems supported: Android, iOS
Supported resolutions: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Performance
Output bandwidth: 60 Mbit/s
Video recording modes: 960p, 720p, 1080p
Video formats supported: H.265+, H.264+, H.265, H.264
Video input channels: 4 channels
Maximum resolution: 3840 x 2160 pixels
Input bandwidth: 80 Mbit/s
Video motion detection: Yes
Audio formats supported: G.726, PCM, G.711 μ-law, G.711 A-law
Image formats supported: MJPEG
Operating system installed: Embedded LINUX
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Audio RCA inputs: 1
Networking standards: IEEE 802.3at, IEEE 802.3af
HDMI ports quantity: 1
Power over Ethernet (PoE): Yes
Ethernet LAN data rates: 100, 10
USB 2.0 ports quantity: 2
Audio RCA outputs: 1
eSATA ports quantity: 1
Power over Ethernet (PoE) ports quantity: 4
VGA (D-Sub) output ports: 1
Hard drive
Maximum storage capacity: 20 TB
HDD interface: SATA
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
