Processor
Built-in processor: Yes
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Features
Rack capacity: 1U
Product colour: Black
Rack mounting: Yes
Power
Power consumption (max): 25.5 W
Output voltage: 53 V
Total Power over Ethernet (PoE) budget: 72 W
Output current: 1.22 A
Power consumption (typical): 10 W
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Package width: 374 mm
Depth: 232.5 mm
Package height: 311 mm
Weight: 890 g
Package depth: 119 mm
Width: 260 mm
Package weight: 2.05 kg
Height: 47.6 mm
System requirements
Browser supported: Chrome; IE; Safari; Edge; Firefox
Mobile operating systems supported: Android, iOS
Supported resolutions: 12 MP;8 MP;6 MP;5 MP;4 MP;3
MP;1080p;720p;960p;D1;CIF;QCIF
Performance
Video recording modes: 960p, 1080p, 720p
Maximum resolution: 3840 x 2160 pixels
Operating system installed: Embedded LINUX
Video formats supported: H.264+, H.265+, H.264, H.265
Audio formats supported: PCM, G.711 A-law, G.711 μ-law, G.726
Image formats supported: MJPEG
Video input channels: 8 channels
Video motion detection: Yes
Input bandwidth: 144 Mbit/s
Output bandwidth: 72 Mbit/s
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
USB 2.0 ports quantity: 2
Networking standards: IEEE 802.3at, IEEE 802.3af
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
Internal SATA ports quantity: 1
Audio RCA outputs: 1
Audio RCA inputs: 1
VGA (D-Sub) output ports: 1
Hard drive
HDD interface: SATA
Maximum storage capacity: 20 TB
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
