Processor
Built-in processor: Yes
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Features
Product colour: Black
Rack mounting: Yes
Rack capacity: 1U
Power
Power consumption (typical): 10 W
Output current: 2 A
Output voltage: 12 V
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Package weight: 1.38 kg
Package width: 334 mm
Package depth: 89 mm
Height: 47.6 mm
Depth: 232.5 mm
Weight: 810 g
Package height: 314 mm
Width: 260 mm
System requirements
Mobile operating systems supported: Android, iOS
Browser supported: Chrome; IE; Safari; Edge; Firefox
Supported resolutions: 1 HDMI, 1 VGA Simultaneous： HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous： HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Performance
Video motion detection: Yes
Face detection: Yes
Input bandwidth: 80 Mbit/s
Audio formats supported: G.711 μ-law, G.711 A-law, G.726, PCM
Image formats supported: MJPEG
Maximum resolution: 3840 x 2160 pixels
Video formats supported: H.265+, H.264+, H.265, H.264
Video input channels: 4 channels
Multi-screen: Yes
Operating system installed: Embedded LINUX
Video recording modes: 720p, 1080p, 960p
Output bandwidth: 60 Mbit/s
Wireless LAN features
Wi-Fi: No
Ports & interfaces
eSATA ports quantity: 1
Ethernet LAN data rates: 10, 100
USB 2.0 ports quantity: 2
Power over Ethernet (PoE): Yes
Audio RCA outputs: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
VGA (D-Sub) output ports: 1
Audio RCA inputs: 1
Hard drive
Maximum storage capacity: 20 TB
