Design
Product colour: Black
Housing material: Metal
Power
Input current: 2.22 A
Power supply included: Yes
Power consumption (max): 110 W
Power protection features: Over voltage, Over current
Power source: DC
DC input voltage: 54 V
Security
Loop protection: Yes
DHCP features: DHCP client
IP-MAC-Port binding: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
Switch type: Managed
Switch layer: L2
Cloud-managed: Yes
Weight & dimensions
Weight: 550 g
Width: 190 mm
Depth: 106 mm
Height: 30 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z, IEEE 802.3u
Virtual LAN features: Port-based VLAN
VLAN support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Number of VLANs: 32
Flow control support: Yes
Performance
Mean time between failures (MTBF): 1115911.8 h
Packaging data
Package height: 87 mm
Package weight: 1.3 kg
Package width: 256 mm
Package depth: 244 mm
Packaging content
Quick start guide: Yes
Cables included: DC
Certificates
Compliance certificates: CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
MAC address table: 8000 entries
Switching capacity: 20 Gbit/s
Jumbo frames support: Yes
Packet buffer memory: 4 MB
Forwarding rate: 14.88 Mpps
Jumbo frames: 15
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 110 W
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE) power per port: 30 W
