Technical details
Automatic gain control: Yes
Wall mountable: Yes
Colour: No
Connectivity technology: Wireless
Sustainability compliance: Yes
VoIP protocols: RTSP, DNS, P2P, UPnP, RTP, RTMP, SIP, SSH, HTTP/HTTPS, ONVIF
Door station control: Yes
Maximum number of cameras supported: 1
Motion detection function: Yes
Speakerphone: Yes
Fingerprint reader: Yes
Built-in microphone: Yes
RFID reader: Yes
Compliance certificates: CE, Federal Communications Commission (FCC)
Design
International Protection (IP) code: IP65
Control type: Touch
Proper use: Outdoor
Housing material: Polycarbonate (PC), Acrylonitrile butadiene styrene (ABS)
Product colour: Light grey
Placement supported: Vertical
Power
Power consumption (standby): 3.5 W
Outdoor unit power type: DC
AC adapter output voltage: 33 V
AC adapter output current: 1 A
Power consumption (typical): 6 W
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Width: 50 mm
Depth: 30 mm
Weight: 180 g
Height: 160 mm
Network
Ethernet interface type: Fast Ethernet
Ethernet LAN data rates: 10, 100
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 4 (802.11n)
Cabling technology: 10/100Base-T(X)
Supported network protocols: RTSP, DNS, P2P, UPnP, RTP, RTMP, SIP, SSH, HTTP/HTTPS, ONVIF
Power over Ethernet (PoE): Yes
Wi-Fi: Yes
Ethernet LAN (RJ-45) ports: 1
Packaging data
Package weight: 400 g
Outdoor unit included: Yes
Display
Touchscreen: Yes
Video formats supported: H.265, H.264
Audio
Voice codecs: PCM, G.711a, G.711u
Noise-canceling: Yes
Built-in speaker(s): Yes
Storage
Memory card slot: Yes
Maximum memory card size: 256 GB
Compatible memory cards: SD, MicroSD (TransFlash)
Camera
Supported video modes: 1080p, 720p
Viewing angle, vertical: 62°
Sensor type: CMOS
Maximum frame rate: 30 fps
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Viewing angle, horizontal: 110°
Megapixel (approx.): 2 MP
Logistics data
Minimum order quantity: 1 pc(s)
Quantity per pack: 1 pc(s)
Night vision
LED type: IR
Night vision: Yes
