Design
Product colour: White
IK code: IK10
Form factor: Dome
Housing material: Metal
International Protection (IP) code: IP67
Mounting type: Ceiling/Wall/Pole
Power
Power consumption (Power over Ethernet (PoE)): 3.8 W
Power consumption (typical): 2.3 W
Power consumption (max): 8.5 W
DC output voltage: 12
Power source type: DC, PoE
Security
Video motion detection: Yes
Privacy protection: Yes
Active tampering alarm: Yes
Alarm input channels: 1
Alarm output channels: 1
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Intrusion, Tripwire, Human detection
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Management features
Web-based management: Yes
Weight & dimensions
Weight: 410 g
Diameter: 10.9 cm
Height: 55 mm
Network
Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
Number of users: 6 user(s)
Bluetooth: No
Ethernet LAN: Yes
Wi-Fi: No
Performance
Connectivity technology: Wired
Built-in light: Yes
Alarm input/output: Yes
Infrared (IR) cut-off filter: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Outdoor
Type: IP security camera
Packaging data
Package weight: 550 g
Packaging content
Number of cameras: 1
Audio
Voice codecs: PCM, G.711Mu, G.711a, G.726
Signal-to-Noise Ratio (SNR): 56 dB
Built-in microphone: Yes
Audio input channels: 1.0 channels
Audio output channels: 1.0 channels
Storage
RAM capacity: 128 MB
Maximum memory card size: 256 GB
Built-in HDD: No
ROM capacity: 128 MB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0.0006 lx
White balance: Street lamp, Manual, Auto, Outdoor, Natural, Regional custom
Lens viewing angle, diagonal: 120°
Pan range: -30 - 30°
Angle of rotation: 360°
Tilt angle range: 0 - 80°
Lens viewing angle, vertical: 54°
Lens viewing angle, horizontal: 101°
Camera shutter speed: 1/3 – 1/100000
Number of Privacy masking areas: 4
Image sensor
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Sensor type: CMOS
Progressive scan: Yes
Video
Supported graphics resolutions: 1920 x 1080 (HD 1080), 1280 x 720 (HD 720), 352 x 240, 352 x 288, 2560 x 1440, 704 x 576, 1280 x 960, 704 x 480, 2688 x 1520, 640 x 480 (VGA)
Video streaming: Yes
Highlight Compensation (HLC): Yes
Gain control type: Auto/Manual
Video compression formats: M-JPEG, H.264H, H.265, H.264, H.264B
Total megapixels: 4 MP
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Maximum resolution: 2688 x 1520 pixels
Back Light Compensation (BLC): Yes
Noise reduction: Yes
Bit rate: H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps
Region of Interest (ROI) encoding: Yes
Noise reduction technology: 3D noise reduction
Flip & mirror: Yes
Night vision
LED type: IR/White
Number of illumination LEDs: 4
Night vision: Yes
Night vision distance: 30 m
Lens system
Recognize distance: 12.7 m
Identify distance: 6.4 m
Fixed focal length: 2.8 mm
Fixed focus: Yes
Closest focusing distance: 1.7 m
Observe distance: 25.4 m
Number of lenses: 1
Detect distance: 63.6 m
