Design
Product colour: White
Form factor: Turret
Mounting type: Ceiling
International Protection (IP) code: IP67
Power
DC output voltage: 12
Power consumption (max): 5.2 W
Power consumption (Power over Ethernet (PoE)): 2.5 W
Power consumption: 2.1 mA
Power source type: DC, PoE
Security
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Intrusion, Tripwire, Human detection
Mirror: Yes
Privacy protection: Yes
Video motion detection: Yes
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web browser: Yes
Management software: DSS; DMSS
Weight & dimensions
Depth: 109.9 mm
Height: 100.9 mm
Width: 109.9 mm
Weight: 370 g
Diameter: 11 cm
Network
Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Ethernet LAN: Yes
Streaming method: Multicast
Number of users: 6 user(s)
Ethernet interface type: Fast Ethernet
System requirements
Mobile operating systems supported: iOS, Android
Certification: CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Performance
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Dynamic range: 120 dB
Connectivity technology: Wired
Placement supported: Indoor & outdoor
Packaging data
Package weight: 510 g
Packaging content
Number of cameras: 1
Audio
Signal-to-Noise Ratio (SNR): 56 dB
Voice codecs: G.711a, G.726, G.711Mu, PCM
Bit rate range: 12 - 6144 Kbit/s
Built-in microphone: Yes
Storage
Compatible memory cards: MicroSD (TransFlash)
ROM capacity: 128 MB
Card reader integrated: Yes
Maximum memory card size: 256 GB
Internal memory: 128 MB
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Camera
Camera shutter type: Electronic
Tilt angle range: 0 - 78°
Angle of rotation: 360°
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0.008 lx
Pan range: 0 - 360°
Lens viewing angle, horizontal: 95°
Lens viewing angle, vertical: 52°
Adjustment shutter speed: Auto/Manual
Lens viewing angle, diagonal: 114°
Image sensor
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Progressive scan: Yes
Number of sensors: 1
Sensor type: CMOS
Video
Maximum resolution: 2688 x 1520 pixels
Total megapixels: 4 MP
Gain control type: Auto/Manual
Video formats supported: H.265+, H.264+, H.265, H.264
Video streaming: Yes
Supported graphics resolutions: 2560 x 1440, 640 x 480 (VGA), 2520 x 1520, 1280 x 960, 1280 x 720 (HD 720), 2304 x 1296, 1920 x 1080 (HD 1080)
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC): Yes
Bit rate: H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps
Noise reduction: Yes
Video compression formats: M-JPEG, H.264H, H.264, H.264B, H.265
Frame rate: 30 fps
Back Light Compensation (BLC): Yes
Privacy masking: Yes
Supported video modes: 1080p
Noise reduction technology: 3D noise reduction
Night vision
Number of illumination LEDs: 2
Night vision distance: 30 m
LED type: IR
Night vision: No
Lens system
Number of lenses: 1
Identify distance: 6.4 m
Recognize distance (tele): 17.1 m
Closest focusing distance: 0.9 m
Identify distance (wide): 6.4 m
Recognize distance: 12.7 m
Detect distance (wide): 63.6 m
Maximum aperture number: 1.6
Recognize distance (wide): 12.7 m
Observe distance (wide): 25.4 m
Observe distance: 25.4 m
Observe distance (tele): 34.2 m
Identify distance (tele): 8.5 m
Detect distance: 63.6 m
Detect distance (tele): 85.4 m
Normal focusing range: 0.9 - 1.6 m
Panoramic camera
Number of Privacy masking areas (panoramic camera): 4
