Design
Product colour: White
Mounting type: Ceiling/wall
Form factor: Bullet
Housing material: Metal
International Protection (IP) code: IP67
Power
Power consumption (Power over Ethernet (PoE)): 2.5 W
Power consumption (typical): 2.1 W
Power source type: DC, PoE
Power consumption (max): 4.4 W
Security
Intelligent Video Surveillance (IVS) system features: Tripwire, Intrusion
Video motion detection: Yes
Privacy protection: Yes
Mirror: Yes
HTTPS encryption: Yes
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web-based management: Yes
Web browser: Yes
Management software: DSS; DMSS
Weight & dimensions
Height: 70 mm
Depth: 166.2 mm
Weight: 480 g
Width: 70 mm
Network
Bluetooth: No
Number of users: 6 user(s)
Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Fast Ethernet
System requirements
Mobile operating systems supported: iOS, Android
Certification: CE-LVD: EN 62368-1
CE-EMC: 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Performance
Connectivity technology: Wired
Placement supported: Indoor & outdoor
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Packaging data
Package weight: 590 g
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Audio formats supported: G.726, G.711 A-law, G.711 μ-law, PCM
Signal-to-Noise Ratio (SNR): 56 dB
Storage
ROM capacity: 128 MB
Internal memory: 128 MB
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Card reader integrated: Yes
Maximum memory card size: 256 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 90°
Camera shutter speed: 1/3 - 1/100000 s
Adjustment shutter speed: Auto/Manual
Angle of rotation: 360°
Minimum illumination: 0.0008 lx
White balance: Street lamp, Natural, Auto, Manual, Outdoor
Pan range: 0 - 360°
Image sensor
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Sensor type: CMOS
Progressive scan: Yes
Video
Maximum resolution: 2688 x 1520 pixels
Privacy masking: Yes
Gain control type: Auto/Manual
Total megapixels: 4 MP
Region of Interest (ROI) encoding: Yes
Highlight Compensation (HLC): Yes
Video compression formats: H.265+, H.264H, H.264B, M-JPEG, H.264, H.264+, H.265
Noise reduction: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Noise reduction technology: 3D noise reduction
Supported graphics resolutions: 2304 x 1296, 352 x 288, 1920 x 1080 (HD 1080), 704 x 480, 2688 x 1520, 342 x 240, 640 x 480 (VGA), 704 x 576, 1280 x 960, 2560 x 1440, 1280 x 720 (HD 720)
Back Light Compensation (BLC): Yes
Night vision
Night vision: Yes
Night vision distance: 30 m
Number of illumination LEDs: 1
LED type: IR
Lens system
Number of lenses: 2
Closest focusing distance: 0.9 m
Maximum aperture number: 1.6
Fixed focus: Yes
Safety warning
Warnings: Avoid exposure of the device to direct water or moisture., It is forbidden to open the device yourself; service and repairs should be performed by qualified personnel., The product contains electronic components; do not dispose of with the normal household waste., Start up and operate the unit in accordance with the operating instructions to avoid the risk of electric shock., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
