Design
Mounting type: Pole clamp
Product colour: White
Form factor: Bullet
Housing material: Metal
International Protection (IP) code: IP67
Power
DC output voltage: 12
Power consumption (max): 4.4 W
Power consumption (typical): 2.5 W
Power source type: DC, PoE
Security
Video motion detection: Yes
Mirror: Yes
Network access storage (NAS): Yes
Human and vehicle targets classification: Yes
IP address filtering: Yes
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Weight: 470 g
Length: 169.8 mm
Width: 70 mm
Height: 70 mm
Network
Streaming method: Multicast
Quality of Service (QoS) support: Yes
Ethernet interface type: Fast Ethernet
Bluetooth: No
Ethernet LAN: Yes
Networking standards: IEEE 802.1x
Wi-Fi: No
System requirements
Mobile operating systems supported: iOS, Android
Performance
Placement supported: Indoor
Dynamic range: 120 dB
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Connectivity technology: Wired
Day/night mode: Yes
Packaging data
Package weight: 590 g
Packaging content
Manual: Yes
Number of cameras: 1
Audio
Audio formats supported: G.726, G.711 A-law, PCM, G.711 μ-law
Built-in microphone: Yes
Storage
RAM capacity: 256 MB
ROM capacity: 128 MB
Maximum memory card size: 256 GB
Built-in HDD: No
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Camera pan control: Yes
Camera tilt control: Yes
Number of Privacy masking areas: 4
Lens viewing angle, horizontal: 112°
Lens viewing angle, diagonal: 132°
Lens viewing angle, vertical: 61°
Camera shutter speed: 1/3 - 1/100000 s
Tilt angle range: 0 - 90°
White balance: Regional custom, Street lamp, Auto, Natural, Manual, Outdoor
Angle of rotation: 360°
Pan range: 0 - 360°
Minimum illumination: 0.0007 lx
Image sensor
Number of sensors: 1
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Video compression formats: H.264B, H.264, H.264H, M-JPEG, H.265
Video streaming: Yes
Gain control type: Auto/Manual
Video recording: Yes
Highlight Compensation (HLC): Yes
Total megapixels: 6 MP
Frame rate: 30 fps
Noise reduction: Yes
Region of Interest (ROI) encoding: Yes
Maximum resolution: 3288 x 1850 pixels
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Noise reduction technology: 3D noise reduction
Back Light Compensation (BLC): Yes
Night vision
Night vision: Yes
Colour night vision distance: 30 m
LED type: IR
Night vision distance: 30 m
Number of illumination LEDs: 2
Lens system
Identify distance: 6.1 m
Closest focusing distance: 1 m
Fixed focus: Yes
Maximum aperture number: 1.6
Fixed focal length: 2.8 mm
Observe distance: 24.5 m
Detect distance: 61.2 m
Recognize distance: 12.2 m
Sustainability
Compliance certificates: CE
