Design
Product colour: Black
Form factor: Bullet
Housing material: Metal, Plastic
Mounting type: Ceiling/wall
International Protection (IP) code: IP67
Power
Power consumption (max): 76 W
Power consumption (typical): 4.5 W
Power consumption (Power over Ethernet (PoE)): 9.1 W
DC output voltage: 12
Power source type: DC, PoE
Security
Video motion detection: Yes
Alarm input channels: 1
Alarm output channels: 1
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Width: 94.4 mm
Length: 288.4 mm
Height: 84.7 mm
Network
Bluetooth: No
Ethernet LAN: Yes
Networking standards: IEEE 802.3af
Number of users: 20 user(s)
Live view: Yes
Ethernet interface type: Fast Ethernet
Wi-Fi: No
System requirements
Mobile operating systems supported: iOS, Android
Certification: CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive; 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B
Performance
Type: IP security camera
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired
Dynamic range: 120 dB
Alarm input/output: Yes
Placement supported: Indoor & outdoor
Packaging content
Number of cameras: 1
Audio
Audio formats supported: PCM, G.711 A-law, G.726
Audio output channels: 1.0 channels
Signal-to-Noise Ratio (SNR): 56 dB
Built-in microphone: Yes
Audio input channels: 1.0 channels
Storage
Internal memory: 512 MB
Maximum memory card size: 256 GB
Card reader integrated: Yes
ROM capacity: 128 MB
Built-in HDD: No
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 90°
White balance: Natural, Auto, Manual, Street lamp, Outdoor
Angle of rotation: 360°
Adjustment shutter speed: Auto/Manual
Minimum illumination: 0.007 lx
Camera shutter type: Electronic
Camera shutter speed: 1/3 - 1/100000 s
Pan range: 0 - 360°
Lens viewing angle, horizontal: 360°
Lens viewing angle, vertical: 90°
Lens viewing angle, diagonal: 360°
Number of Privacy masking areas: 4
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Number of sensors: 1
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Video
Supported graphics resolutions: 704 x 480, 1280 x 720 (HD 720), 2688 x 1512, 352 x 240, 2304 x 1296, 640 x 480 (VGA), 3072 x 2048, 3840 x 2160, 2592 x 1944, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 3072 x 1728, 352 x 288, 2668 x 1512, 704 x 576, 1280 x 960
Video formats supported: H.264B, H.264+, H.265, H.265+, H.264
Bit rate: 3 kbps-20480 kbps
Maximum resolution: 3840 x 2160 pixels
Privacy masking: Yes
Gain control type: Auto/Manual
Total megapixels: 8 MP
Video compression formats: H.264+, H.264B, H.264, H.265+, H.265
Region of Interest (ROI) encoding: Yes
Video streaming: Yes
Frame rate: 20 fps
Noise reduction: Yes
Back Light Compensation (BLC): Yes
Smart IR: Yes
Highlight Compensation (HLC): Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Noise reduction technology: 3D noise reduction
Night vision
LED type: White
Number of illumination LEDs: 2
Night vision distance: 30 m
Night vision: Yes
Lens system
Recognize distance: 18.2 m
Number of lenses: 1
Fixed focal length: 3.6 mm
Observe distance: 36.4 m
Detect distance: 91 m
Identify distance: 9.1 m
Closest focusing distance: 4.4 m
