Certification: FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014
Features
Rack capacity: 1U
Product colour: White
Rack mounting: Yes
Power
Output voltage: 12 V
Power consumption (typical): 10 W
Output current: 2 A
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Package depth: 96 mm
Weight: 450 g
Package weight: 1.07 kg
Width: 204.6 mm
Package height: 261 mm
Package width: 364 mm
Height: 45.6 mm
Depth: 206.4 mm
System requirements
Mobile operating systems supported: Android, iOS
Browser supported: Chrome; IE9 and later; Firefox
Supported resolutions: 1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
Performance
Maximum resolution: 3840 x 2160 pixels
Multi-screen: Yes
Backup function: Yes
Operating system installed: Embedded LINUX
Video input channels: 4 channels
Video formats supported: H.264+, H.265+, H.265, H.264
Face detection: Yes
People counting: Yes
Video recording modes: 960p, 1080p, 720p
Audio formats supported: G.711 μ-law, PCM, G.726, G.711 A-law
Image formats supported: MJPEG
Output bandwidth: 80 Mbit/s
Input bandwidth: 80 Mbit/s
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Ethernet LAN data rates: 10, 100
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) output ports: 1
HDMI output: Yes
Audio RCA outputs: 1
Audio RCA inputs: 1
Hard drive
HDD interface: SATA
Maximum storage capacity: 16 TB
