Technical details
Compliance certificates: CE, Federal Communications Commission (FCC)
Certification: EN IEC 61000-3-2:2019+A1:2021;
EN 61000-3-3:2013+A1:2019+A2:2021; EN
55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014
Features
Rack capacity: 1U
Product colour: White
Rack mounting: Yes
Power
Power over Ethernet (PoE) power per port: 25.5 W
Power consumption (max): 10 W
Total Power over Ethernet (PoE) budget: 72 W
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Package weight: 1.74 kg
Package width: 427 mm
Depth: 206.2 mm
Height: 47.5 mm
Package height: 262 mm
Package depth: 96 mm
Width: 270 mm
Weight: 700 g
System requirements
Mobile operating systems supported: iOS, Android
Browser supported: Chrome; IE9 and later; Firefox
Supported resolutions: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
Performance
Input bandwidth: 256 Mbit/s
Output bandwidth: 256 Mbit/s
Maximum resolution: 3840 x 2160 pixels
Audio formats supported: G.726, G.711 μ-law, PCM, G.711 A-law
Video formats supported: H.264+, H.265+, H.265, H.264
Image formats supported: MJPEG
Face detection: Yes
Operating system installed: Embedded LINUX
People counting: Yes
Multi-screen: Yes
Video recording modes: 720p, 1080p, 960p
Backup function: Yes
Video input channels: 8 channels
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Audio RCA inputs: 1
HDMI output: Yes
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
Power over Ethernet (PoE): Yes
HDMI ports quantity: 1
Networking standards: IEEE 802.3at, IEEE 802.3af
USB 2.0 ports quantity: 2
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
DC-in jack: Yes
Power over Ethernet (PoE) ports quantity: 8
Ethernet LAN (RJ-45) ports: 1
Hard drive
Maximum storage capacity: 16 TB
HDD interface: SATA
