Certification: FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014
Features
Product colour: White
Rack mounting: Yes
Rack capacity: 1U
Power
Power consumption (typical): 10 W
Output current: 2 A
Output voltage: 12 V
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 93%
Weight & dimensions
Weight: 450 g
Package weight: 1.07 kg
Height: 45.6 mm
Package depth: 96 mm
Width: 204.6 mm
Depth: 206.4 mm
Package width: 364 mm
Package height: 261 mm
System requirements
Mobile operating systems supported: iOS, Android
Browser supported: Chrome; IE9 and later; Firefox
Supported resolutions: 1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
Performance
Face detection: Yes
Video formats supported: H.265, H.264, H.264+, H.265+
Audio formats supported: G.726, PCM, G.711 μ-law, G.711 A-law
People counting: Yes
Video recording modes: 720p, 960p, 1080p
Maximum resolution: 3840 x 2160 pixels
Multi-screen: Yes
Video input channels: 8 channels
Image formats supported: MJPEG
Backup function: Yes
Operating system installed: Embedded LINUX
Input bandwidth: 80 Mbit/s
Output bandwidth: 80 Mbit/s
Wireless LAN features
Wi-Fi: No
Ports & interfaces
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 10, 100
HDMI ports quantity: 1
VGA (D-Sub) output ports: 1
HDMI output: Yes
Audio RCA outputs: 1
Audio RCA inputs: 1
Hard drive
Maximum storage capacity: 16 TB
HDD interface: SATA
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
