Technical details
Compliance certificates: Federal Communications Commission (FCC), CE
Certification: EN IEC 61000-3-2:2019+A1:2021;
EN 61000-3-3:2013+A1:2019+A2:2021; EN
55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014
Features
Rack mounting: Yes
Rack capacity: 1U
Product colour: Black
Power
Power consumption (typical): 25.5 W
Power consumption (max): 10 W
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Package width: 433 mm
Width: 375 mm
Height: 53 mm
Depth: 284.3 mm
Package depth: 141 mm
Package height: 366 mm
Package weight: 2.76 kg
Weight: 1.51 kg
System requirements
Mobile operating systems supported: Android, iOS
Browser supported: Chrome; IE9 and later; Firefox
Supported resolutions: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
Performance
Alarm input channels: 4
Audio formats supported: G.711 A-law, G.726, PCM, G.711 μ-law
Operating system installed: Embedded LINUX
People counting: Yes
Image formats supported: MJPEG
Multi-screen: Yes
Face detection: Yes
Backup function: Yes
Input bandwidth: 256 Mbit/s
Output bandwidth: 256 Mbit/s
Video formats supported: H.265+, H.265, H.264, H.264+
Video recording modes: 1080p, 720p, 960p
Video input channels: 8 channels
Alarm output channels: 2
Maximum resolution: 3840 x 2160 pixels
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Power over Ethernet (PoE): Yes
VGA (D-Sub) output ports: 1
Power over Ethernet (PoE) ports quantity: 8
HDMI output: Yes
Audio RCA outputs: 1
Audio RCA inputs: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
Networking standards: IEEE 802.3at, IEEE 802.3af
DC-in jack: Yes
Ethernet LAN data rates: 10, 1000, 100
Ethernet LAN (RJ-45) ports: 1
Hard drive
Maximum storage capacity: 16 TB
Number of HDDs supported: 2
HDD interface: SATA
