Design
Product colour: White, Black
Mounting type: Ceiling/Wall/Pole
IK code: IK10
Fog proof: Yes
Form factor: Dome
International Protection (IP) code: IP67
Power
Power source type: DC, PoE
Power consumption (typical): 10 W
Power consumption (max): 22 W
DC output voltage: 24
Security
Motion sensor: Yes
Operational conditions
Operating temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 4.7 kg
Height: 332 mm
Diameter: 19 cm
Network
Number of users: 20 user(s)
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Streaming method: Unicast, Multicast
Certification: CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
UL: UL60950-1+CAN/CSA C22.2, No.60950-1
Performance
Connectivity technology: Wired
Type: IP security camera
Placement supported: Indoor & outdoor
Alarm input/output: Yes
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Packaging data
Package weight: 8 kg
Packaging content
Number of cameras: 1
Audio
Signal-to-Noise Ratio (SNR): 55 dB
Storage
ROM capacity: 4096 MB
Maximum memory card size: 512 GB
Card reader integrated: Yes
Internal memory: 1024 MB
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Number of Privacy masking areas: 24
Tilt angle range: -15 - 90°
Camera shutter speed: 1/1 - 1/30,000 s
Camera shutter type: Electronic
White balance: Natural, Auto, Street lamp, ATW, Indoor, Manual, Sodium lamp, Outdoor
Pan speed: 400 °/sec
Minimum illumination: 0.0005 lx
Pan range: 0 - 360°
Tilt speed: 300 °/sec
Tilt manual speed: 0.1 - 200 °/sec
Lens viewing angle, horizontal: 58.4°
Lens viewing angle, diagonal: 66.4°
Pan manual speed: 0.1 - 300 °/sec
Lens viewing angle, vertical: 33.4°
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 480 (VGA), 352 x 288, 1280 x 720 (HD 720), 704 x 576, 1280 x 960
Maximum resolution: 1920 x 1080 pixels
Video streaming: Yes
Privacy masking: Yes
Gain control type: Auto/Manual
Total megapixels: 2 MP
Frame rate: 30 fps
Bit rate: 64 kbps–10496 kbps
Noise reduction: Yes
Region of Interest (ROI) encoding: Yes
Highlight Compensation (HLC): Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Smart IR: Yes
Back Light Compensation (BLC): Yes
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Video compression formats: H.264B, H.265+, M-JPEG, H.264H, H.264, H.264+, H.265
Night vision
Night vision: Yes
LED type: IR
Lens system
Auto focus: Yes
Closest focusing distance: 0.1 m
Maximum aperture number: 1.5
Optical zoom: 32x
Minimum aperture number: 4
Focal length range: 4.5 - 144 mm
Focus: Motorized/Manual
Digital zoom: 16x
