Processor
Built-in processor: Yes
Power
DC voltage: 12 V
Power consumption (typical): 10 W
Operational conditions
Operating temperature (T-T): -10 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 0 - 90%
Storage temperature (T-T): -20 - 70 °C
Weight & dimensions
Width: 260 mm
Weight: 890 g
Height: 47.6 mm
Depth: 231.4 mm
Network
Ethernet interface type: Fast Ethernet
Number of users: 128 user(s)
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN: Yes
Playback resolutions supported: 1920 x 1080, 1280 x 1024, 1280 x 720
Performance
Video compression formats: H.265+, H.265, H.264+, H.264
Video streaming: Yes
Rack capacity: 1U
Dual stream support: Yes
Operating system installed: Embedded LINUX
Video motion detection: Yes
PTZ control: Yes
Product colour: Black
Bit rate: 4096 Kbit/s
Video capturing speed: 30 fps
Audio system: 2-way
Audio formats supported: G.711u, PCM, G.711
Maximum video resolution: 1920 x 1080 pixels
Internal: No
Analog signal format system: PAL, NTSC
Graphical user interface (GUI): Yes
Ports & interfaces
HDMI ports quantity: 1
BNC input ports: 16
Audio input: 1
Video input channels: 16 channels
VGA (D-Sub) output ports: 1
Audio output: 1
USB 2.0 ports quantity: 2
Hard drive
Number of HDDs supported: 1
HDD interface: SATA, SATA III, SATA II
Maximum HDD capacity: 6 TB
