Power
DC voltage: 12 V
Power supply type: DC
Power consumption (typical): 7 W
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Weight: 530 g
Depth: 237.9 mm
Height: 47.6 mm
Width: 260 mm
Network
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
Certification: FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024
Performance
Video capturing speed (PAL): 25 fps
Product colour: Black
Video compression formats: H.264+, H.265, H.264, H.265+
Rack capacity: 1U
Audio formats supported: PCM, G.711 A-law, G.711 μ-law
Maximum video resolution: 3840 x 2160 pixels
Video capturing speed: 30 fps
Video loss detection: Yes
Video motion detection: Yes
PTZ control: Yes
Video capturing speed (NTSC): 30 fps
Channels quantity: 4 channels
Backup function: Yes
Operating system installed: Embedded LINUX
Packaging data
Package width: 333 mm
Package height: 89 mm
Package weight: 1.07 kg
Package depth: 315 mm
Display
Built-in display: No
Ports & interfaces
USB 2.0 ports quantity: 2
Audio output: 1 RCA
RS-485 ports: 1
Video input channels: 4 channels
BNC input ports: 4
Audio input: 1
HDMI ports quantity: 1
Hard drive
HDD interface: SATA
Number of HDDs supported: 1
Maximum HDD capacity: 16 TB
Safety warning
Warnings: Do not disassemble by yourself, the product may contain hazardous substances., Avoid direct contact with internal electronic components., Dispose of according to local environmental regulations.
