Power
DC current (max): 2 A
Power supply type: DC
Power consumption (typical): 7 W
DC voltage: 12 V
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Depth: 237.8 mm
Height: 47.6 mm
Weight: 880 g
Width: 260 mm
Network
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Performance
Playback modes: Backup selection, Stop, Full screen, Zoom, Play, Previous, Next, Repeat, Pause, Fast, Shuffle, Slow
Rack capacity: 1U
Operating system installed: Embedded LINUX
Maximum frame rate: 60 fps
Video motion detection: Yes
Video compression formats: H.264, H.265, H.265+, H.264+
PTZ control: Yes
Video loss detection: Yes
Multi-display supported: Yes
Multi-display modes: 4, 9, 8
Dual stream support: Yes
Audio system: 2-way
Video streaming: Yes
Video capturing speed: 30 fps
Backup function: Yes
Internal: Yes
Bit rate: 32 Kbit/s
Product colour: Black
USB connectivity: Yes
Maximum video resolution: 3840 x 2160 pixels
Analog signal format system: PAL, NTSC
LED indicators: Power, HDD, Network
Channels quantity: 8 channels
Packaging data
Package depth: 89 mm
Package width: 344 mm
Package weight: 1.45 kg
Package height: 287 mm
Ports & interfaces
VGA (D-Sub) output ports: 1
RS-485 ports: 1
Video input channels: 4 channels
Audio input: 1
HDMI ports quantity: 1
Audio output: 1
USB 2.0 ports quantity: 1
Hard drive
Number of HDDs supported: 1
HDD interface: SATA
Maximum HDD capacity: 10 TB
