Power
Power supply type: DC
DC voltage: 12 V
Power consumption (typical): 4 W
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Height: 47.6 mm
Depth: 237.9 mm
Width: 260 mm
Weight: 840 g
Network
Ethernet interface type: Fast Ethernet
Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 1
Playback resolutions supported: 1920 x 1080, 1280 x 1024, 1280 x 720
Certification: FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024
Performance
Operating system installed: Embedded LINUX
Analog signal format system: NTSC, PAL
Backup function: Yes
Maximum frame rate: 60 fps
Video compression formats: H.265+, H.265, H.264+, H.264
Audio formats supported: G.711 μ-law, PCM, G.711 A-law
PTZ control: Yes
Dual stream support: Yes
Video loss detection: Yes
Video motion detection: Yes
Channels quantity: 4 channels
Video streaming: Yes
Video capturing speed: 30 fps
Maximum video resolution: 1920 x 1080 pixels
Audio system: 2-way
Product colour: Black
Rack capacity: 1U
Packaging data
Package width: 344 mm
Package weight: 1.41 kg
Package height: 287 mm
Package depth: 89 mm
Ports & interfaces
RS-485 ports: 1
Video input channels: 4 channels
BNC output ports: 1
Audio input: 1 RCA
BNC input ports: 4
VGA (D-Sub) output ports: 1
Audio output: 1 RCA
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
Hard drive
Number of HDDs supported: 1
Maximum HDD capacity: 16 TB
HDD interface: SATA
