Processor
Built-in processor: Yes
Power
Power supply type: DC
DC voltage: 12 V
Power consumption (typical): 10 W
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Height: 47.6 mm
Weight: 900 g
Width: 260 mm
Depth: 237.9 mm
Network
Ethernet interface type: Gigabit Ethernet
Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 1
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Performance
Operating system installed: Embedded LINUX
Audio formats supported: PCM, G.711 A-law, G.711 μ-law
Video compression formats: H.265, H.264, H.264+, H.265+
Backup function: Yes
Video loss detection: Yes
Video motion detection: Yes
Maximum video resolution: 1920 x 1080 pixels
Channels quantity: 8 channels
Product colour: Black
LED indicators: Yes
Packaging data
Package height: 315 mm
Package weight: 1.5 kg
Package width: 330 mm
Package depth: 89 mm
Packaging content
Quick start guide: Yes
Ports & interfaces
VGA (D-Sub) output ports: 1
RS-485 ports: 1
Video input channels: 8 channels
Audio output: 1
BNC input ports: 8
Audio input: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 2.0 ports quantity: 2
Hard drive
Number of HDDs supported: 1
Maximum HDD capacity: 16 TB
HDD interface: SATA
