Technical details
Compliance certificates: CE
Power
DC voltage: 12 V
Power supply type: DC
Power consumption (typical): 15 W
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Depth: 257.1 mm
Width: 325 mm
Weight: 1.39 kg
Height: 55 mm
Network
Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, P2P
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Ethernet LAN: Yes
Performance
Product colour: Black
Video loss detection: Yes
Audio formats supported: G.711u, PCM, G.711 A-law
Maximum video resolution: 3840 x 2160 pixels
USB connectivity: Yes
Multi-display supported: Yes
Video motion detection: Yes
Playback modes: Smart, Tag, Instant, Event, General
Rack capacity: 1U
Operating system installed: Embedded LINUX
Dual stream support: Yes
Backup function: Yes
Multi-display modes: 16, 1, 25, 8, 36, 4, 9
Audio output channels: 1.0 channels
Graphical user interface (GUI): Yes
Video compression formats: H.265, H.264+, H.264, H.265+
Audio input channels: 16 channels
Packaging data
Package width: 374 mm
Package depth: 119 mm
Package height: 311 mm
Package weight: 2.06 kg
Packaging content
Quick start guide: Yes
Ports & interfaces
BNC input ports: 16
RS-485 ports: 1
Video RCA outputs: 1
VGA (D-Sub) output ports: 1
HDMI ports quantity: 1
Video input channels: 16 channels
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 2.0 ports quantity: 1
Video
Video resolutions: 1280 x 720, 3840 x 2160, 1920 x 1080
Hard drive
Maximum HDD capacity: 16 TB
Number of HDDs supported: 1
