Technical details
Compliance certificates: CE
Power
Power consumption (typical): 15 W
Power supply type: DC
DC voltage: 12 V
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Width: 375 mm
Depth: 289.6 mm
Height: 53 mm
Weight: 1.75 kg
Network
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN: Yes
Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, P2P
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Ethernet LAN (RJ-45) ports: 1
Performance
Video compression formats: H.265, H.264+, H.264, H.265+
Product colour: Black
Backup function: Yes
Playback modes: Instant, Tag, Event, Smart, General
Audio formats supported: PCM, G.711u, G.711
Audio input channels: 16 channels
Video loss detection: Yes
Rack capacity: 1U
Operating system installed: Embedded LINUX
Maximum video resolution: 3840 x 2160 pixels
USB connectivity: Yes
Video motion detection: Yes
Multi-display supported: Yes
Audio output channels: 1.0 channels
Dual stream support: Yes
Multi-display modes: 9, 1, 4, 25, 16, 36, 8
Graphical user interface (GUI): Yes
Packaging data
Package width: 427 mm
Package height: 356 mm
Package depth: 137 mm
Package weight: 2.9 kg
Packaging content
Quick start guide: Yes
Ports & interfaces
USB 2.0 ports quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) output ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
BNC input ports: 16
RS-485 ports: 1
Video input channels: 16 channels
Video RCA outputs: 1
Video
Video resolutions: 3840 x 2160, 1920 x 1080, 1280 x 720
Hard drive
Number of HDDs supported: 2
Maximum HDD capacity: 16 TB
