Technical details
Warranty period: 5 year(s)
Compliance certificates: RoHS, CE, WEEE
System requirements
Windows operating systems supported: Windows 8 x64, Windows XP, Windows Vista x64, Windows 11, Windows 7, Windows 8.1 x64, Windows 11 x64, Windows 8, Windows XP Professional x64, Windows 8.1, Windows Vista, Windows 7 x64, Windows 10 x64, Windows 10, Windows 2000
Linux operating systems supported: Linux Kernel 5.12, Linux Kernel 6.5, Linux Kernel 5.15, Linux Kernel 5.9, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 6.2, Linux Kernel 5.11, Linux Kernel 5.19, Linux Kernel 5.8, Linux Kernel 5.10, Linux Kernel 5.4
Server operating systems supported: Windows Server 2008 R2, Windows Server 2022, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2008 R2 x64, Windows Server 2012 x64, Windows Server 2019, Windows Server 2012 R2 x64, Windows Server 2003, Windows Server 2008 x64, Windows Server 2003 R2, Windows Server 2008, Windows Server 2016 x64, Windows Server 2003 x64
Performance
JBOD function: Yes
Form factor: Low Profile PCIe
RAID levels: 1, SPAN, 0, JBOD
RAID Level Migration: Yes
S.M.A.R.T. support: Yes
Channels quantity: 2 channels
Hot-swap: Yes
Data transfer rate: 6 Gbit/s
SSD support: Yes
Chipset: Marvell 88SE9170
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
PCI Express slots version: 2.0
Supported storage drive interfaces: Serial ATA, Serial ATA III, Serial ATA II
Internal SATA ports quantity: 2
Host interface: PCI Express
Other features
PCI Card form factor: Half-height (low-profile)
Hot-Plug support: Yes
Manual: Yes
Maximum supported storage capacity: 512 TB
Drivers included: Yes
Logistics data
Harmonized System (HS) code: 84733080
