Technical details
Compliance certificates: RoHS, CE, WEEE
Warranty period: 5 year(s)
System requirements
Server operating systems supported: Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 x64, Windows Server 2016 x64, Windows Server 2012 R2 x64, Windows Server 2012, Windows Server 2003, Windows Server 2008 x64, Windows Server 2003 R2, Windows Server 2008 R2 x64, Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2008, Windows Server 2003 x64
Linux operating systems supported: Linux Kernel 5.14, Linux Kernel 6.2, Linux Kernel 5.10, Linux Kernel 5.8, Linux Kernel 5.15, Linux Kernel 5.9, Linux Kernel 5.11, Linux Kernel 5.19, Linux Kernel 5.12, Linux Kernel 6.5, Linux Kernel 5.13, Linux Mint 10, Linux Kernel 5.4
Windows operating systems supported: Windows 8, Windows 10, Windows XP Professional x64, Windows 8.1, Windows Vista, Windows 7 x64, Windows 10 x64, Windows 2000, Windows 8 x64, Windows XP, Windows 7, Windows 8.1 x64, Windows 11 x64, Windows Vista x64, Windows 11
Performance
RAID Level Migration: Yes
Data transfer rate: 6 Gbit/s
Hot-swap: Yes
Channels quantity: 2 channels
SSD support: Yes
S.M.A.R.T. support: Yes
Chipset: Marvell 88SE9170
Form factor: Low Profile PCIe
RAID levels: SPAN, 0, 1, JBOD
JBOD function: Yes
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
Host interface: PCI Express
Supported storage drive interfaces: Serial ATA, Serial ATA III, Serial ATA II
Internal SATA ports quantity: 2
eSATA ports quantity: 1
PCI Express slots version: 2.0
Other features
Hot-Plug support: Yes
Maximum supported storage capacity: 512 TB
Drivers included: Yes
Manual: Yes
Logistics data
Harmonized System (HS) code: 84733080
