Technical details
Compliance certificates: RoHS, CE, WEEE
Warranty period: 5 year(s)
Processor
Built-in processor: Yes
System requirements
Windows operating systems supported: Windows 10 x64, Windows 8.1, Windows Vista, Windows 7 x64, Windows XP Professional x64, Windows 8 x64, Windows XP, Windows Vista x64, Windows 11, Windows 8, Windows 2000, Windows 7, Windows 8.1 x64, Windows 11 x64, Windows 10
Server operating systems supported: Windows Server 2003, Windows Server 2008 x64, Windows Server 2003 R2, Windows Server 2022, Windows Server 2016 x64, Windows Server 2012 x64, Windows Server 2012 R2 x64, Windows Server 2008 R2, Windows Server 2019, Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2008, Windows Server 2012 R2, Windows Server 2016, Windows Server 2003 x64
Linux operating systems supported: Linux Kernel 5.15, Linux Kernel 5.9, Linux Kernel 5.13, Linux Kernel 5.8, Linux Kernel 5.11, Linux Kernel 5.19, Linux Kernel 5.12, Linux Kernel 6.5, Linux Kernel 5.10, Linux Kernel 5.4, Linux Kernel 5.14, Linux Kernel 6.2
Performance
S.M.A.R.T. support: Yes
Form factor: Low Profile PCIe
Hot-swap: Yes
Chipset: Marvell 88SE9230
RAID levels: 0, 5, SPAN, 1, 10, JBOD
Channels quantity: 4 channels
Data transfer rate: 6 Gbit/s
RAID Level Migration: Yes
SSD support: Yes
JBOD function: Yes
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
Supported storage drive interfaces: Serial ATA
Host interface: PCI Express x2
eSATA ports quantity: 2
Internal SATA ports quantity: 4
PCI Express slots version: 2.0
Other features
Hot-Plug support: Yes
Drivers included: Yes
Maximum supported storage capacity: 512 TB
Manual: Yes
Logistics data
Harmonized System (HS) code: 84733080
