Technical details
Warranty period: 5 year(s)
Compliance certificates: RoHS, CE, WEEE
Processor
Processor model: Marvell 88SE9230
Built-in processor: Yes
System requirements
Windows operating systems supported: Windows 8, Windows 10 x64, Windows Vista x64, Windows 11, Windows 8.1, Windows Vista, Windows 7 x64, Windows 8 x64, Windows XP, Windows 10, Windows 2000, Windows 8.1 x64, Windows 11 x64, Windows XP Professional x64, Windows 7
Server operating systems supported: Windows Server 2008 R2 x64, Windows Server 2008, Windows Server 2003, Windows Server 2008 x64, Windows Server 2003 R2, Windows Server 2019, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2022, Windows Server 2012, Windows Server 2012 x64, Windows Server 2016 x64, Windows Server 2012 R2 x64, Windows Server 2013, Windows Server 2003 x64
Linux operating systems supported: Linux Kernel 5.12, Linux Kernel 6.5, Linux Kernel 5.8, Linux Kernel 5.15, Linux Kernel 5.9, Linux Kernel 5.11, Linux Kernel 5.19, Linux Kernel 5.13, Linux Kernel 5.10, Linux Kernel 5.14, Linux Kernel 6.2, Linux Kernel 5.4
Performance
RAID levels: 1, 5, 10, SPAN, 0, JBOD
Form factor: Low Profile PCIe
JBOD function: Yes
S.M.A.R.T. support: Yes
Data transfer rate: 6 Gbit/s
Hot-swap: Yes
Channels quantity: 4 channels
RAID Level Migration: Yes
SSD support: Yes
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
PCI Express slots version: 2.0
Supported storage drive interfaces: M.2, Serial ATA III, Serial ATA II, Serial ATA
Internal SATA ports quantity: 4
Host interface: PCI Express x4
Other features
Hot-Plug support: Yes
Drivers included: Yes
Maximum supported storage capacity: 512 TB
Manual: Yes
