Design
Stackable: Yes
Rack mounting: Yes
Form factor: 1U
Product colour: Black
Power
Power source: AC/DC
Power supply included: Yes
DC input voltage: 48 V
AC input voltage: 230 V
Security
DHCP features: DHCP snooping, DHCP client, DHCP Option 82, DHCP server, DHCP Option 60, DHCP Option 43, DHCPv6 snooping
SSH/SSL support: Yes
MAC address filtering: Yes
IGMP snooping: Yes
Loop protection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 50 °C
Management features
Switch layer: L2/L3
Web-based management: Yes
System event log: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Depth: 230 mm
Width: 440 mm
Network
Virtual LAN features: Voice VLAN, Port-based VLAN, MAC address-based VLAN
Networking standards: IEEE 802.1w, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae
Broadcast storm control: Yes
10G support: Yes
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Port mirroring: Yes
Number of VLANs: 4000
VLAN support: Yes
Performance
Flash memory: 160 MB
Ports & interfaces
Combo SFP ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 16
Basic switching RJ-45 Ethernet ports quantity: 8
Console port: RS-232/RJ-45
Number of management ports: 1 pc(s)
USB Type-A ports quantity: 1
SFP+ module slots quantity: 4
USB 2.0 ports quantity: 1
Data transmission
MAC address table: 16000 entries
Jumbo frames support: Yes
Jumbo frames: 10000
Forwarding rate: 95.23 Mpps
Switching capacity: 128 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
