Design
Fan connector: 4-pin
Display size (HxV): 29 x 39 mm
Product colour: Black
Number of heat pipes: 5
Number of fans: 1 fan(s)
Number of fan blades: 7
Radiator material: Aluminum
Power
Fan voltage: 12 V
Fan power consumption: 3 W
Fan current: 0.25 A
Weight & dimensions
Radiator depth: 12.7 cm
Heat pipes diameter: 6 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Radiator width: 8.9 cm
Width: 117 mm
Depth: 129 mm
Weight: 1.36 kg
Radiator height: 15.3 cm
Height: 159 mm
Performance
Quantity per pack: 1 pc(s)
Supported processor sockets: LGA 1156 (Socket H), LGA 1700, LGA 1851, LGA 1150 (Socket H3), Socket AM5, LGA 1200 (Socket H5), LGA 1151 (Socket H4), Socket AM4, LGA 1155 (Socket H2)
Pulse-width modulation (PWM) support: Yes
Fan noise level (max): 31.45 dB
Maximum air pressure: 3.33 mmH2O
Type: Air cooler
Suitable location: Processor
Fan speed (max): 2200 RPM
Maximum airflow: 63.4 cfm
Fan diameter: 12 cm
Fan bearing technology: Hydro Dynamic Bearing (HDB)
Packaging content
Mounting kit: Yes
Package type: Box
Screws included: Yes
CPU bracket(s): Yes
Other features
Built-in display: Yes
