Design
Fan connector: 4-pin
Number of fan blades: 7
Product colour: Black
Radiator material: Aluminum
Number of heat pipes: 6
Number of fans: 2 fan(s)
Power
Fan current: 0.19 A
Fan voltage: 12 V
Fan power consumption: 2.28 W
Weight & dimensions
Radiator height: 15.3 cm
Width: 144 mm
Weight: 1.39 kg
Heat pipes diameter: 6 mm
Radiator depth: 12.5 cm
Height: 159 mm
Radiator width: 11.5 cm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Depth: 127 mm
Performance
Maximum air pressure: 2.78 mmH2O
Maximum airflow: 57.76 cfm
Supported processor sockets: Socket AM4, LGA 1851, LGA 1156 (Socket H), LGA 1700, LGA 1200 (Socket H5), LGA 1151 (Socket H4), LGA 1150 (Socket H3), Socket AM5, LGA 1155 (Socket H2)
Type: Air cooler
Fan speed (max): 2200 RPM
Fan diameter 2: 12 cm
Quantity per pack: 1 pc(s)
Fan bearing technology: Hydro Dynamic Bearing (HDB)
Fan noise level (max): 28.87 dB
Suitable location: Processor
Pulse-width modulation (PWM) support: Yes
Fan 2 rotational speed (max): 2000 RPM
Fan diameter: 12 cm
Packaging content
Package type: Box
Mounting kit: Yes
CPU bracket(s): Yes
Screws included: Yes
