Design
Fan connector: 4-pin
Product colour: Black
Number of fans: 2 fan(s)
Number of fan blades: 9
Number of heat pipes: 6
Power
Rated voltage: 12 V
Fan power consumption: 1.44 W
Thermal Design Power (TDP): 260 W
Rated current: 0.12 A
Weight & dimensions
Heat pipes diameter: 6 mm
Depth: 138 mm
Width: 129 mm
Height: 160 mm
Weight: 1.46 kg
Radiator width: 12.7 cm
Fan 2 dimensions (W x D x H): 120 x 120 x 25 mm
Radiator height: 15.7 cm
Radiator depth: 11 cm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Quantity per pack: 1 pc(s)
Supported processor sockets: LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 1700, LGA 1155 (Socket H2), LGA 1200 (Socket H5), Socket AM4, LGA 2011 (Socket R), LGA 2066, LGA 1150 (Socket H3), Socket AM5
Pulse-width modulation (PWM) support: Yes
Rotational speed (max): 1850 RPM
Maximum air pressure: 2.19 mmH2O
Bearing type: Fluid Dynamic Bearing (FDB)
Maximum airflow: 68.99 cfm
Fan diameter: 12 cm
Noise level (high speed): 28 dB
Suitable location: Processor
Fan diameter 2: 12 cm
Rotational speed (min): 500 RPM
Type: Air cooler
Packaging content
Mounting kit: Yes
Package type: Box
Thermal pad included: Yes
