Design
Number of heat pipes: 7
Fan connector: 4-pin
Number of fans: 2 fan(s)
Product colour: Black
Power
Fan voltage: 12 V
Fan power consumption: 2.88 W
Fan current: 0.1 A
Weight & dimensions
Height: 164 mm
Fan dimensions (W x D x H): 140 x 140 x 25 mm
Depth: 147 mm
Fan 2 dimensions (W x D x H): 120 x 120 x 25 mm
Heat pipes diameter: 6 mm
Width: 144 mm
Weight: 1.57 kg
Performance
Supported processor sockets: LGA 1700, LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 2011 (Socket R), LGA 1150 (Socket H3), Socket AM5, Socket AM4, LGA 2066, LGA 1200 (Socket H5), LGA 1155 (Socket H2)
Fan speed (max): 1700 RPM
Suitable location: Processor
Fan noise level (min): 22.6 dB
Pulse-width modulation (PWM) support: Yes
Maximum air pressure: 2.44 mmH2O
Fan noise level (max): 29.3 dB
Fan diameter: 14 cm
Maximum airflow: 79.1 cfm
Fan bearing technology: Fluid Dynamic Bearing (FDB)
Quantity per pack: 1 pc(s)
Fan speed (min): 500 RPM
Type: Air cooler
Packaging content
Mounting kit: Yes
Screws included: Yes
Adapter frame included: Yes
CPU bracket(s): Yes
Package type: Box
Safety warning
Warnings: Take appropriate precautions during installation to avoid damage to computer components., Ensure that the unit is switched off before starting to assemble or dismantle the cooling unit., Do not touch the fan during operation.
