Design
Number of heat pipes: 7
Display size (HxV): 44.6 x 53.6 mm
Number of fans: 2 fan(s)
Fan connector: 4-pin
Product colour: Black
Power
Fan current: 0.2 A
Fan voltage: 12 V
Power consumption (typical): 4.8 W
Rated voltage: 12 V
Thermal Design Power (TDP): 300 W
Weight & dimensions
Depth: 144 mm
Height: 172 mm
Fan dimensions (W x D x H): 140 x 140 x 25 mm
Radiator width: 14 cm
Width: 147 mm
Radiator height: 16 cm
Radiator depth: 11 cm
Heat pipes diameter: 6 mm
Weight: 1.78 kg
Fan 2 dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Bearing type: Fluid Dynamic Bearing (FDB)
Suitable location: Processor
Rotational speed (max): 1800 RPM
Rotational speed (min): 500 RPM
Pulse-width modulation (PWM) support: Yes
Maximum air pressure: 3.76 mmH2O
Maximum airflow: 61.25 cfm
Fan diameter: 120/140 mm
Fan noise level (max): 29.3 dB
Quantity per pack: 1 pc(s)
Supported processor sockets: LGA 2066, LGA 2011 (Socket R), LGA 1700, LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 1851, LGA 1200 (Socket H5), LGA 1155 (Socket H2)
Fan 2 maximum airflow: 58.06 cfm
Fan 2 maximum air pressure: 2.1 mmH2O
Type: Air cooler
Packaging content
Mounting kit: Yes
Package type: Box
