Design
LED connector type: 3-pin
Fan connector: 4-pin
Display type: IPS
Number of fans: 2 fan(s)
Radiator material: Aluminum
Illumination LED: Yes
Number of fan blades: 9
Product colour: White
Power
LED power consumption (pump): 1.5 W
LED power consumption (fan): 3.5 W
Pump current: 290 mA
Pump voltage: 12 V
Fan voltage: 12 V
Pump power consumption: 3.48 W
Fan current: 0.18 A
LED voltage: 5 V
Fan power consumption: 2.16 W
Weight & dimensions
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Radiator depth: 28.2 cm
Radiator height: 2.7 cm
Radiator width: 12 cm
Pump depth: 9 cm
Weight: 1.4 kg
Pump height: 6.3 cm
Pump width: 8 cm
Tube length: 41 cm
Performance
Pump connector: 4-pin
Fan noise level (max): 36.07 dB
Fan diameter: 12 cm
Pulse-width modulation (PWM) support: Yes
Pump motor speed (min): 2500 RPM
Maximum air pressure: 3.27 mmH2O
Maximum airflow: 66.23 cfm
Pump motor speed (max): 3400 RPM
Fan speed (max): 2400 RPM
Fan speed (min): 400 RPM
Bearing type: Hydraulic
Quantity per pack: 1 pc(s)
Suitable location: Processor
Type: Liquid cooling kit
Supported processor sockets: LGA 1151 (Socket H4), LGA 1155 (Socket H2), Socket AM4, LGA 1150 (Socket H3), Socket AM5, LGA 1700, LGA 1851, LGA 1200 (Socket H5)
Packaging content
CPU bracket(s): Yes
CPU socket spacer(s): Yes
Screws included: Yes
Cables included: 3-pin, 4-pin
Mounting kit: Yes
Package type: Box
