Design Product colour: Black On/off switch: Yes Fan diameter: 12 cm Cooling type: Active Number of fans: 1 fan(s)
Power Max output current (+12V): 40 A Total power: 500 W Combined power (+3.3V): 100 W Power protection features: Under voltage, Short circuit, Over voltage, Over power Efficiency: 85% Combined power (-12V): 3.6 W Combined power (+12V): 480 W Max output current (-12V): 0.3 A Hold time: 16 ms Max output current (+5Vsb): 2.5 A AC input frequency: 50 Hz Max output current (+3.3V): 15 A Combined power (+5V): 100 W AC input voltage: 220 - 240 V Combined power (+5Vsb): 12.5 W Max output current (+5V): 15 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Purpose: PC/Server Power supply unit (PSU) form factor: ATX ATX version: 2.4 Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS
Packaging data Package type: Box
Packaging content Cables included: AC
Ports & interfaces Motherboard power cable length: 55 cm SATA power cable length: 750, 900, 600 mm, 450 EPS power connector (4+4 pin): Yes Number of SATA power connectors: 4 Cabling type: Non-Modular Motherboard power connector: 20+4 pin ATX PCI Express power connectors (6+2 pin): 2
