Design Product colour: Black Number of fans: 1 fan(s) Fan diameter: 12 cm Cooling type: Active On/off switch: Yes
Power Total power: 700 W Max output current (+3.3V): 15 A Combined power (-12V): 3.6 W Combined power (+3.3V): 100 W Max output current (+5Vsb): 2.5 A Efficiency: 85% Max output current (+12V): 58 A Power protection features: Short circuit, Over voltage, Over power, Under voltage AC input voltage: 220 - 240 V Combined power (+5Vsb): 12.5 W Max output current (-12V): 0.3 A Combined power (+12V): 696 W Combined power (+5V): 100 W AC input frequency: 50 Hz Hold time: 12 ms Max output current (+5V): 15 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance Purpose: PC/Server Power supply unit (PSU) form factor: ATX ATX version: 2.4 80 PLUS certification: 80 PLUS Mean time between failures (MTBF): 100000 h
Packaging data Package type: Box
Packaging content Cables included: AC
Ports & interfaces SATA power cable length: 450, 900 mm, 600, 750 mm Cabling type: Non-Modular Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes Motherboard power cable length: 55 cm PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 4
