Design
Number of fans: 1 fan(s)
On/off switch: Yes
Product colour: Black
Fan diameter: 12 cm
Power
Power protection features: NLO, OCP (overcurrent protection), OPP (overload protection), SIP (surge and shock protection), OVP (overvoltage protection), SCP (short circuit protection), OTP (overheat protection), UVP (undervoltage protection)
Total power: 550 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm
Performance
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
ATX version: 3.0
Cooling type: Active
Efficiency: 85 %
Packaging data
Package type: Box
Packaging content
Cables included: AC
Ports & interfaces
Cabling type: Non-Modular
ATX power connector (20+4 pin): Yes
PCI Express power connectors (6+2 pin): 3
Number of SATA power connectors: 6
Motherboard power connector: 20+4 pin ATX
Power supply connectors: EPS12V
Number of power connectors 12VHPWR (12V - 2x6 pin): 1
CPU power connectors 4+4 (8-pin) : 2
Safety warning
Warnings: The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Do not open the case - risk of electric shock.
