Technical details
Sustainability certificates: Triman, ErP
Sustainability compliance: Yes
Design
Fan location: Top
Product colour: Black
On/off switch: Yes
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Power
Total power: 800 W
Combined power (+5Vsb): 15 W
Efficiency: 85%
Power protection features: No load operation, Surge & inrush protection (SIP), Overheating, Surge protection, Over voltage, Under voltage, Over current, Over power
Hold time: 16 ms
Power Good signal delay range: 100 - 150 ms
Combined power (-12V): 3.6 W
Power Factor Correction (PFC) type: Active
Max output current (+3.3V): 20 A
Combined power (+12V): 648 W
Max output current (+12V): 54 A
AC input voltage: 100 - 240 V
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
AC input frequency: 50/60 Hz
Input current: 9 - 4.5 A
Max output current (+5V): 20 A
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm
Performance
Bearing technology: HYB
ATX version: 3.0
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Purpose: PC
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Certification: CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH
Certificates
Compliance certificates: RoHS, WEEE
Ports & interfaces
PCI Express power connectors (16-pin): 1
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 3
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 55 cm
ATX power connector (20+4 pin): Yes
SATA power cable length: 550, 450, 650
Number of SATA power connectors: 6
CPU power connector (4+4 pin): Yes
Cabling type: Non-Modular
