Design
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Fan location: Top
Cooling type: Active
Product colour: Black
Power
Power Good signal delay range: 100 - 150 ms
AC input voltage: 100 - 240 V
Power protection features: Overheating, Surge protection, Short circuit, Over voltage, Over power, No load operation, Surge & inrush protection (SIP), Under voltage
Combined power (+5V): 120 W
Combined power (+12V): 999.6 W
Total power: 1000 W
Combined power (+3.3V): 120 W
Power Factor Correction (PFC) type: Active
AC input frequency: 50/60 Hz
Combined power (+5Vsb): 15 W
Efficiency: 90%
Hold time: 16 ms
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 150 mm
Performance
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
ATX version: 3.1
Bearing technology: FDB
Purpose: PC
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Packaging content
Cable tie(s) included: Yes
Cables included: AC
Ports & interfaces
PCI Express power connectors (16-pin): 1
Number of SATA power connectors: 8
Motherboard power connector: 20+4 pin ATX
ATX power connector (20+4 pin): Yes
CPU power connector (4+4 pin): 2
CPU power cable length: 70 cm
Cabling type: Fully-Modular
PCI Express power connectors (6+2 pin): 3
Peripheral (Molex) power connectors (4-pin): 2
Safety warning
Warnings: Avoid contact of the product with water or other liquids., Do not open the case - risk of electric shock., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
