Technical details
Sustainability certificates: Triman, ErP
Design
Cooling type: Active
Product colour: Black
Fan diameter: 9.2 cm
Number of fans: 1 fan(s)
Power
Power protection features: No load operation, Short circuit, Under voltage, Over current, Overheating, Over voltage, Over power, Surge & inrush protection (SIP)
Total power: 850 W
Input current: 10 - 5 A
Max output current (+12V): 70.8 A
AC input voltage: 100 - 240 V
Hold time: 16 ms
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
Max output current (+5Vsb): 3 A
Max output current (+3.3V): 20 A
Max output current (+5V): 20 A
Combined power (+12V): 849.6 W
Efficiency: 90%
Power Factor Correction (PFC) type: Active
AC input frequency: 50/60 Hz
Combined power (-12V): 3.6 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 100 mm
Width: 125 mm
Height: 63.5 mm
Performance
Purpose: PC
Power supply unit (PSU) form factor: SFX
Bearing technology: FDB
Mean time between failures (MTBF): 100000 h
ATX version: 3.1
Packaging data
Manual: Yes
Package type: Box
Packaging content
Cables included: CPU, PCIe, Peripheral (Molex), SATA, AC
Cable tie(s) included: Yes
Certification: Cybenetics Platinum/PPLP Gold
ATX3.1
Certificates
Compliance certificates: KC, RoHS, CE, ICES, RCM, EAC, CCC, TÜV mark
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 1
Number of SATA power connectors: 3
CPU power cable length: 50 cm
Peripheral (Molex) power cable length: 120
Motherboard power cable length: 35 cm
Cabling type: Fully-Modular
SATA power cable length: 120, 300
PCI Express connector: Yes
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (6+2 pin): 3
PCI Express power cable length: 45 cm
CPU power connector (4+4 pin): Yes
PCI Express power connectors (16-pin): 1
Logistics data
Warranty period: 5 year(s)
