Processor
Processor generation: Intel Core Ultra (Series 2)
Maximum turbo power: 121 W
Processor base power: 65 W
Efficient cores: 4
Efficient-core base frequency: 2.7 GHz
Performance-core base frequency: 3.3 GHz
Performance cores: 6
Processor cores: 10
Processor model: 225
Performance-core Max Turbo Frequency: 4.9 GHz
Processor threads: 10
Processor boost frequency: 4.9 GHz
Processor family: Intel Core Ultra 5
Processor cache: 20 MB
Number of processors installed: 1
Efficient-core Max Turbo Frequency: 4.4 GHz
Processor cache type: Smart Cache
Processor manufacturer: Intel
Graphics
On-board GPU manufacturer: Intel
On-board graphics card model: Intel® Graphics
Discrete graphics card model: Not available
On-board graphics card family: Intel® Graphics
On-board graphics card: Yes
Discrete graphics card: No
Memory
Memory data transfer rate: 5600 MT/s
Internal memory: 16 GB
Maximum internal memory: 64 GB
Internal memory type: DDR5-SDRAM
Memory channels: Single-channel
Memory slots: 2x DIMM
Memory layout (slots x size): 1 x 16 GB
Design
Cable lock slot: Yes
Cable lock slot type: Kensington
Product colour: Black
Chassis type: Slim PC
Power
Power supply input frequency: 47/63 Hz
Power supply input voltage: 90 - 264 V
Power supply: 180 W
80 PLUS certification: 80 PLUS Bronze
Operational conditions
Non-operating vibration: 1.37 G
Non-operating shock: 105 G
Operating shock: 40 G
Operating vibration: 0.26 G
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 10 - 35 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 20 - 80%
Operating altitude: -15.2 - 3048 m
Non-operating altitude: -15.2 - 10668 m
Weight & dimensions
Weight: 4.75 kg
Height: 303.5 mm
Width: 95 mm
Depth: 293 mm
Network
WLAN controller model: MediaTek MT7920
MU-MIMO: Yes
WLAN controller manufacturer: MediaTek
Antenna type: 2x2
Bluetooth: Yes
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), 802.11b
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Ethernet LAN: Yes
Performance
Trusted Platform Module (TPM) version: 2.0
Motherboard chipset: Intel SoC
Trusted Platform Module (TPM): Yes
Product type: PC
Packaging content
Mouse included on selected markets: Dell Optical Mouse-MS116 - Black
Keyboard included on selected markets: Dell Wired Keyboard - KB216 - UK (QWERTY) - Black
Display
Display included: No
Software
Operating system installed: Windows 11 Pro
Trial software: McAfee LiveSafe 1Yr,Microsoft Office Trial
Operating system architecture: 64-bit
Audio
Audio system: High Definition Audio
Audio chip: Realtek ALC3204
Storage
SSD capacity: 512 GB
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD interface: PCI Express 4.0
NVMe: Yes
SSD form factor: M.2
Optical drive type: No
Total storage capacity: 512 GB
Number of storage drives installed: 1
Storage media: SSD
Ports & interfaces
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
HDMI version: 2.1
Carbon footprint
Total carbon footprint (kg of CO2e): 148
Carbon emissions, logistics (kg of CO2e): 9.176
Carbon emissions, end-of-life (kg of CO2e): 2.96
Carbon emissions, energy usage (kg of CO2e): 62.752
Carbon emissions, manufacturing (kg of CO2e): 73.26
PAIA version: GaBi version 1, 2024
Neural processor unit (NPU)
GPU performance up to: 4 TOPs
AI software frameworks supported by NPU: OpenVINO, WebNN, DirectML, ONNX RT, Windows ML
Total processor performance up to: 23 TOPs
NPU performance up to: 13 TOPs
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
