Processor Memory types supported by processor: DDR5-SDRAM Thermal Design Power (TDP): 55 W Memory clock speeds supported by processor: 4800 MHz Processor threads: 8 Processor boost frequency: 5.2 GHz Processor manufacturer: Intel Processor model: 6325P Performance cores: 4 Processor family: Intel Xeon 6 Processor cache: 12 MB Processor frequency: 3.5 GHz System bus rate: 16 GT/s
Memory Memory layout (slots x size): 1 x 32 GB ECC: Yes Memory slots: 4x DIMM Memory data transfer rate: 5600 MT/s Internal memory: 32 GB Buffered memory type: Unregistered (unbuffered) Internal memory type: DDR5-SDRAM Maximum internal memory: 128 GB
Design Bezel: Yes Chassis type: Rack (1U) Product colour: Black
Power Power cable connector 1: C13 coupler Power supply: 700 W Number of main power supplies: 1 Power cable current: 10 A Power cable length: 2 m Redundant power supply (RPS) support: No Power cable connector 2: C14 coupler Power supply input voltage: 200 - 240 V
Expansion slots PCI Express x8 slots: 1 PCI Express x16 slots: 1 Compatible operating systems: Canonical® Ubuntu® Server LTS
Microsoft® Windows Server® with Hyper-V
RedHat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Software Operating system installed: No
Certificates 80 PLUS certification: 80 PLUS Titanium
Storage Drive writes per day (DWPD): 1 SSD interface: SATA III Total storage capacity: 480 GB Hot-Plug support: Yes SSD size: 2.5" Supported SSD sizes: 2.5" Number of SSDs supported: 8 Number of SSDs installed: 1 SSD capacity: 480 GB Supported RAID controllers: Front PERC H755 Front Load RAID support: No
Ports & interfaces USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1 VGA (D-Sub) ports quantity: 1 Serial ports quantity: 1 Ethernet LAN (RJ-45) ports: 2 USB 2.0 ports quantity: 2
Other features Data transfer rate: 6 Gbit/s Target workload: Read Intensive (RI) Bytes per sector: 512e
Carbon footprint Total carbon emissions, standard deviation (kg of CO2e): 943 PAIA version: 1.4.0, 2024 Carbon emissions, energy usage (kg of CO2e): 718.2 Carbon emissions, logistics (kg of CO2e): 102.6 Carbon emissions, end-of-life (kg of CO2e): 11.4 Total carbon footprint (kg of CO2e): 1140 Carbon emissions, manufacturing (kg of CO2e): 307.8
