Processor
Number of processors installed: 1
Processor model: 6507P
Processor boost frequency: 4.2 GHz
Processor cores: 8
Processor manufacturer: Intel
System bus rate: 24 GT/s
Processor threads: 16
Processor family: Intel Xeon 6
Memory types supported by processor: DDR5-SDRAM
Memory clock speeds supported by processor: 6400 MHz
Thermal Design Power (TDP): 150 W
Processor frequency: 3.5 GHz
Processor cache: 48 MB
Memory
Memory layout (slots x size): 1 x 32 GB
Memory slots: 16x DIMM
Buffered memory type: Registered (buffered)
Memory data transfer rate: 6400 MT/s
Memory ranking: 2
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Maximum internal memory: 1 TB
Design
Bezel: Yes
Product colour: Black
Chassis type: Rack (2U)
Power
Number of redundant power supplies installed: 2
Power supply: 1100 W
Redundant power supply (RPS) support: Yes
Power supply input voltage: 100 - 240 V
Weight & dimensions
Width: 482 mm
Height: 86.8 mm
Performance
Remote administration: iDRAC10, Enterprise 17G
Expansion slots
PCI Express x16 (Gen 5.x) slots: 2
Compatible operating systems: Canonical Ubuntu Server LTS
RedHat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Windows Server
Windows Server Datacenter
Software
Operating system installed: No
Certificates
80 PLUS certification: 80 PLUS Titanium
Storage
SSD size: 2.5"
Number of SSDs supported: 16
Hot-Plug support: Yes
Supported SSD sizes: 2.5"
SSD capacity: 960 GB
Total storage capacity: 960 GB
RAID support: Yes
Drive writes per day (DWPD): 1
SSD interface: SATA III
Optical drive type: No
Number of SSDs installed: 1
Supported RAID controllers: PERC H965i Controller, Front, DC-MHS
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
VGA (D-Sub) ports quantity: 1
Other features
Target workload: Read Intensive (RI)
Data transfer rate: 6 Gbit/s
Bytes per sector: 512e
Open Compute Project (OCP): 1x16 FLOP, 1x16 Onboard, 1 Rear Blank
Carbon footprint
Carbon emissions, end-of-life (kg of CO2e): 37.41
Total carbon footprint (kg of CO2e): 1247
Carbon emissions, logistics (kg of CO2e): 209.5
Carbon emissions, manufacturing (kg of CO2e): 463.88
Carbon emissions, energy usage (kg of CO2e): 537.46
Total carbon emissions, standard deviation (kg of CO2e): 101
PAIA version: PAIA 1.4.7, 2025
