Features
LED indicators: Power, Link
DIN rail mounting: Yes
Housing material: Aluminium
Digital Diagnostics Monitoring (DDM): No
Internal: No
International Protection (IP) code: IP40
Product colour: Black, Blue
Power
Power over Ethernet (PoE): No
Input voltage: 12 - 48 V
Power consumption (typical): 3 W
Operational conditions
Storage temperature (T-T): -40 - 80 °C
Operating temperature (T-T): -40 - 80 °C
Weight & dimensions
Width: 118 mm
Depth: 92.4 mm
Weight: 400 g
Height: 40 mm
Network
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Fiber ethernet cabling technology: 1000BASE-FX
Data transfer rate: 1000 Mbit/s
Cable types supported: Cat3, Cat5, Cat4
Converter output interface: 1000Base-FX
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T, 100BASE-T, 1000BASE-TX
Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3i
Converter input interface: 10Base-T, 1000Base-T, 100Base-T, 100Base-TX, 1000Base-TX, 1000Base-FX
Maximum data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Ethernet interface type: Gigabit Ethernet
Duplex system: Full, Half
Performance
Fiber mode structure: Multi-mode, Single-mode
Maximum transfer distance: 80000 m
Mean time between failures (MTBF): 300000 h
Buffer size: 1200 KB
Packaging data
Package depth: 54 mm
Package volume: 1202.85 cm³
Package width: 135 mm
Package weight: 558.333 g
Package height: 165 mm
Packaging content
Quick installation guide: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 2
Fiber optic connector: FX
Connectivity technology: Wired
Logistics data
Country of origin: China
UK Trade Tariff code: 85176200
