Design
LED indicators: Yes
Product colour: Silver, Green
Component for: Server
Internal: Yes
Country of origin: China
Weight & dimensions
Width: 155 mm
Height: 120 mm
Weight: 170 g
Depth: 20 mm
Network
Maximum data transfer rate: 10000 Mbit/s
Networking standards: IEEE 802.1ad, IEEE 802.1Q, IEEE 802.1p
Jumbo frames support: Yes
Ethernet LAN: Yes
Data link protocols: TCP/IP, UDP/IP, IPSec, iSCS
LAN controller: Intel® X540-BT2
Jumbo frames: 9.5
System requirements
Server operating systems supported: Windows Server 2008, Windows Server 2016, Windows Server 2012
Windows operating systems supported: Windows 8, Windows 10, Windows 8.1
Linux operating systems supported: Yes
Packaging data
Package width: 218 mm
Package weight: 280 g
Package depth: 30 mm
Package height: 155 mm
Packaging content
Manual: Yes
Mounting brackets included: Yes
Resource CD: Yes
Ports & interfaces
PCI Card form factor: Full-height (low-profile)
Interface: Ethernet
Host interface: PCI Express
Ethernet LAN (RJ-45) ports: 2
Connectivity technology: Wired
PCI version: 2.1
Other features
Package volume: 1013.7 cm³
Logistics data
UK Trade Tariff code: 84718000
