Design
Stackable: No
Suitable for outdoor use: No
Vandal-proof: No
Rack mounting: Yes
Number of fans: 2 fan(s)
LED indicators: PoE, Link, Activity, Power
Form factor: 1U
Product colour: Silver, Black
Power
Power source: AC
Power supply included: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Unmanaged
Network
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-TX
Head-of-line (HOL) blocking: Yes
VLAN support: Yes
Full duplex: Yes
10G support: No
Auto MDI/MDI-X: Yes
Half duplex: Yes
Networking standards: IEEE 802.3u, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Performance
Mean time between failures (MTBF): 50000 h
Packaging data
Package height: 83 mm
Package volume: 11553.6 cm³
Package width: 480 mm
Package weight: 3.61 kg
Package depth: 290 mm
Packaging content
Rack mount kit: Yes
Quick start guide: Yes
Cables included: AC
Ports & interfaces
Fast Ethernet (copper) ports quantity: 16
Basic switching RJ-45 Ethernet ports quantity: 16
Combo SFP ports quantity: 2
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Other features
Ethernet interface type: Fast Ethernet
Power supply: 270 W
Logistics data
UK Trade Tariff code: 85176200
Country of origin: China
Data transmission
Switching capacity: 7.2 Gbit/s
Store-and-forward: Yes
MAC address table: 8000 entries
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 250 W
Power over Ethernet (PoE) ports quantity: 16
Power over Ethernet (PoE) voltage: 55 V
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): No
