Design Stackable: No DIN rail mounting: Yes Suitable for outdoor use: No International Protection (IP) code: IP40 Housing material: Aluminium Product colour: Blue Vandal-proof: No Rack mounting: No
Power DC input voltage: 12 - 52 V Surge protection voltage: 4 kV Power source: DC Surge protection: Yes Redundant power supply (RPS) support: Yes Power supply included: No Power consumption (typical): 10 W
Operational conditions Operating temperature (T-T): -40 - 80 °C Storage temperature (T-T): -40 - 80 °C Operating relative humidity (H-H): 5 - 95%
Management features Switch type: Unmanaged
Weight & dimensions Depth: 135 mm Height: 45.5 mm Weight: 900 g Width: 175.6 mm
Network 10G support: No Flow control support: Yes Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3i Auto MDI/MDI-X: Yes VLAN support: No Ethernet LAN data rates: 10,100,1000 Mbit/s Full duplex: Yes
Performance Fanless: Yes Mean time between failures (MTBF): 300000 h
Packaging data Package weight: 1.08 kg Package volume: 2804.88 cm³ Package depth: 186 mm Package height: 72.5 mm Package width: 208 mm
