Design
Vandal-proof: No
Suitable for outdoor use: No
DIN rail mounting: Yes
LED indicators: Yes
International Protection (IP) code: IP40
Rack mounting: No
Housing material: Aluminium
Product colour: Black, Blue
Stackable: No
Power
Power consumption (typical): 10 W
DC input voltage: 12 - 52 V
Power source: DC
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 80 °C
Storage temperature (T-T): -40 - 80 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 45.5 mm
Depth: 135 mm
Width: 175.6 mm
Weight: 1 kg
Network
Half duplex: Yes
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3u
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 100BASE-FX, 1000BASE-TX
Full duplex: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Flow control support: Yes
10G support: No
VLAN support: No
Packaging data
Package width: 186 mm
Package volume: 2804.88 cm³
Package depth: 72.5 mm
Package height: 208 mm
Package weight: 1.17 kg
Ports & interfaces
Uplink ports quantity: 2
Gigabit Ethernet (copper) ports quantity: 16
Power connector: Terminal block (6-pin)
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Other features
Ethernet interface type: Gigabit Ethernet
Bandwidth: 56 Gbit/s
Logistics data
UK Trade Tariff code: 85176200
Country of origin: China
Data transmission
Forwarding rate: 42 Mpps
Packet buffer memory: 4.1 MB
Switching capacity: 1 Gbit/s
MAC address table: 8000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
