Design
Internal: Yes
Component for: PC/Server
Product colour: Green, Black
Country of origin: China
Weight & dimensions
Depth: 20 mm
Width: 70 mm
Height: 150 mm
Weight: 150 g
Network
Quality of Service (QoS) support: Yes
Jumbo frames support: Yes
iSCSI support: Yes
Networking standards: IEEE 802.1AX, IEEE 802.3ap, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.3by, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.3ad, IEEE 802.1Qbg, IEEE 802.1p, IEEE 1588v2
Jumbo frames: 9600
Maximum data transfer rate: 25000 Mbit/s
Wake-on-LAN ready: Yes
System requirements
Linux operating systems supported: Yes
Windows operating systems supported: Windows 8, Windows 7, Windows 10, Windows 8.1
Server operating systems supported: Windows Server 2008, Windows Server 2012, Windows Server 2019, Windows Server 2016
Other operating systems supported: FreeBSD
Packaging data
Package height: 220 mm
Package depth: 30 mm
Package weight: 257.5 g
Package width: 155 mm
Packaging content
Manual: Yes
Resource CD: Yes
Mounting brackets included: Yes
Ports & interfaces
Fiber optic connector: SFP28
Interface: Fiber
Host interface: PCI Express
Fiber ports quantity: 2
PCI version: 3.0
Connectivity technology: Wired
PCI Card form factor: Full-height (low-profile)
Other features
Intelligent Offloads: Yes
Package volume: 1023 cm³
PCI-SIG* SR-IOV Capable: Yes
Logistics data
UK Trade Tariff code: 84718000
