Design LED indicators: Power Rack mounting: Yes On/off switch: Yes Form factor: 1U Product colour: Grey
Power AC input voltage: 100 - 240 V Input current: 4.5 A Power protection features: Short circuit, Overload Power consumption (max): 270 W Surge protection: Yes AC input frequency: 50 - 60 Hz
Operational conditions Operating temperature (T-T): -10 - 45 °C Storage relative humidity (H-H): 0 - 95% Operating relative humidity (H-H): 0 - 90% Storage temperature (T-T): -20 - 70 °C
Weight & dimensions Weight: 4.39 kg Width: 345 mm Depth: 440 mm Height: 45 mm
Network Networking standards: IEEE 802.3af Full duplex: Yes Auto MDI/MDI-X: Yes 10G support: No
Performance Plug and Play: Yes Mean time between failures (MTBF): 100000 h
Packaging data Package weight: 5.33 kg Package type: Box Package volume: 19429.9 cm³ Package width: 405 mm Package height: 95 mm Package depth: 505 mm
Packaging content Quick start guide: Yes Cables included: AC
Other features Ethernet interface type: Gigabit Ethernet
Logistics data Harmonized System (HS) code: 85176990 UK Trade Tariff code: 85176200
Power over Ethernet (PoE) Power over Ethernet plus (PoE+) ports quantity: 24 Total Power over Ethernet (PoE) budget: 370 W Power over Ethernet (PoE) voltage range: 1.2 - 3.6 V Power over Ethernet (PoE): Yes Power over Ethernet (PoE) power per port: 30 W
